WS-C3750-24TS-E Cisco 3750 Switch
Manufacturer Part Number: WS-C3750-24TS-E
Brand: Cisco
Condition: Refurbished
The WS-C3750-24TS-E is a highly versatile and reliable Ethernet switch manufactured by Cisco Systems, belonging to the renowned Cisco 3750 Series. With 24 Ethernet ports, this switch provides ample connectivity for devices within a network, supporting high-speed data transfer rates. The “E” designation signifies the Enhanced Image (EI) software feature set, which includes advanced Layer 3 routing capabilities, making it suitable for more complex network configurations. Additionally, the WS-C3750-24TS-E offers features such as Quality of Service (QoS), VLAN support, and comprehensive security features to ensure efficient and secure data transmission. It’s a trusted choice for businesses and organizations requiring a robust and scalable network infrastructure.
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | WS-C3750-24TS-E |
| Product Type | Switch – 24 ports – Managed – stackable |
| Form Factor | Fixed, Rack Mountable 1U, Stackable/Clustering |
| Switch Port density – Uplinks | 24 x 10/100 + 2 x SFP |
| MAC Address Table Size | 12K entries |
| Routing Protocol | OSPF, IGRP, BGP-4, RIP-1, RIP-2, EIGRP, DVMRP, PIM-SM, static IP routing, PIM-DM |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON 2, SNMP, RMON, Telnet, SNMP 3 |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ |
| Features | Flow control, full duplex capability, routing, auto-sensing per device, DHCP support, auto-negotiation, ARP support, trunking, load balancing, VLAN support, IGMP snooping, manageable, stackable |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s |
| DRAM Memory | 128 MB |
| Flash Memory | 16 MB Flash |
| LED Status Lights Indicators | Port status, link activity, port transmission speed, port duplex mode, power |
| Connectivity / Expansion Slots | |
|---|---|
| Interfaces | 24 x 10Base-T/100Base-TX – RJ-45 1 x console – RJ-45 – management Network stack device : 2 x 2 x SFP (mini-GBIC) |
| Power Supply Specifications | |
| Power Device | Power supply – internal |
| Voltage Required | AC 120/230 V ( 50/60 Hz ) |
| Power Consumption Operational | 50 Watt |
| Dimensions / Weight / Miscellaneous | |
| Width | 44.5 cm |
| Depth | 30.1 cm |
| Height | 4.4 cm |
| Weight | 3.6 kg |
| Cables Included | 1 x serial cable |
| MTBF | 294,928 hour(s) |
| Compliant Standards | CE, FCC Class A certified, CSA, UL, TUV GS, CISPR 24, cUL, EN 60950, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN55024 |
