Cisco PWR-C1-350WAC-P 350W AC Platinum-Rated Switch Power Supply
Manufacturer Part Number: PWR-C1-350WAC-P
Brand: Cisco
Product Type: Power Module
Condition: New
Warranty: 1 Year
Specifications:
Power Capacity : 350 W
Input Voltage : 100 to 240 VAC
Output : -56V at 6.25A
Mean Time Between Failures MTBF (hours): 1,335,012 (ranges from 1.3M to 3.1M depending on temperature, input voltage and vendor)
Power connectors: —_x008f_ Customers can provide power to a switch by using the internal power at the back of the switch
—_x008f_ Internal power supply connector: The internal power supply is an auto-ranging unit. It supports input voltages between 100 (115 for 1100WAC) and 240 VAC. Use the supplied AC power cord to connect the AC power connector to an AC power outlet
LED indicators: AC OK: Input power to the power supply is OK – PS OK: Output power from the power supply is OK
Operating temperature: Normal operating temperature* and altitudes: —_x008f_ -5°C to +45°C, up to 5000 feet (1500m) —_x008f_ -5°C to +40°C, up to 10,000 feet (3000m) *Minimum ambient temperature for cold start is 32°F (0°C)
Short-term* exceptional conditions: —_x008f_ -5°C to +50°C, up to 5000 feet (1500m) —_x008f_ -5°C to +45°C, up to 10,000 feet (3000m) —_x008f_ -5°C to +45°C, at sea level with single fan failure *Not more than following in one-year period: 96 consecutive hours, or 360 hours total, or 15 occurrences
Storage temperature: -40° to 158°F (-40° to 70°C)
Altitude: 10,000 ft. (3000 meters), up to 45°C
Relative humidity operating and nonoperating noncondensing: 5% to 90% noncondensing
EMI and EMC compliance: FCC Part 15 (CFR 47) Class A ICES-003 Class A EN 55032 Class A CISPR 32 Class A AS/NZS 3548 Class A BSMI Class A (AC input models only) VCCI Class A EN 55024, EN300386, EN 61000-3-2, EN 61000-3-3 EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6
