Guess what we’ve got for you? A wireless link so strong, you’ll feel like you just plugged in a fiber cable through thin air.
The AVYCON ANCP3005Q isn’t just another outdoor CPE — it’s your go-to long-range wireless bridge for serious connectivity challenges. Built on the rock-solid Qualcomm® Atheros chipset and armed with dual 14dBi integrated antennas, this unit pushes high-speed, low-latency connections up to 6 miles away (yep, six!) with clear line of sight.
Why does this matter? Because whether you’re linking two office buildings, beaming internet to a remote warehouse, or streaming surveillance video from cameras in the middle of nowhere, you need speed you can trust and hardware that won’t quit on you. This CPE avoids the crowded 2.4GHz band entirely, cruising on the cleaner, faster 5.8GHz spectrum to keep your data flowing without dropouts.
It’s weatherproof, IP66-rated, and laughs in the face of -40°F cold or desert heat. Installation? Easy. You get PoE power, LED signal indicators for precise alignment, and mounting options for poles, walls, or racks. And yes, it’ll even power a single IP camera directly — so you can run both data and power over a single cable.
If you’ve ever wished your Wi-Fi could “just work” no matter the distance or weather, the ANCP3005Q is your wish granted.
Key Features & Benefits
-
Long-Range Performance – Up to 6 miles with clear line of sight for stable, high-speed links.
-
High Throughput – Supports up to 300Mbps for seamless video, data, and VoIP traffic.
-
Multi-Mode Flexibility – Operates as Bridge, Access Point, Router, or Repeater.
-
Integrated Power for IP Cameras – PoE output to power a single IP camera directly from the CPE.
-
Durable Outdoor Design – IP66-rated, works in extreme temps from -40°F to 131°F.
-
Easy Deployment – Includes 48V PoE injector, LEDs for signal alignment, and multiple mounting options.
Technical Specifications
| Specification | Details |
|---|---|
| CPU | Qualcomm AR9344 560MHz |
| Memory | 64MB DDR2 / 16MB SPI |
| Antennas | Integrated Dual 14 dBi |
| Wi-Fi Standards | IEEE802.11a/an |
| Security | WPA, WPA2-AES, WPA2-PSK |
| RF Output Power | 200mW (23dBm) |
| RF Sensitivity | -96dBm |
| Frequency Range | 5.180GHz – 5.825GHz |
| Max Data Rate | 300Mbps |
| Ethernet Ports | 1 x WAN (10/100 Mbps), 1 x LAN (10/100 Mbps) |
| PoE Output | Toggle switch for IPC |
| Ingress Protection | IP66 |
| Power Supply | 48V PoE Adapter |
| Power Consumption | <8W |
| Mounting Options | Pole, Wall, Rack |
| Dimensions | 10.2” x 3.1” x 2.1” (262mm x 80mm x 53mm) |
| Weight | 0.7 lbs |
| Operating Temp | -40°F ~ 131°F |
| Storage Temp | -58°F ~ 167°F |
